| General |
| Type |
VGA |
| Usage |
Business |
| Device Chipset |
DLP |
| Display Mode |
SVGA, 1080i, 1080p, 480i, 480p, 576i, 576p, 720p |
| Resolution |
800 x 600 pixels |
| Lamp |
185 W |
| Lamp Life |
3000 hrs |
| Projection Distance |
39.3 inch to 39.3 ft |
| Display Features |
| Maximum Projection Size |
303 inch |
| Brightness |
2500 lm (Maximum) |
| Zoom Ratio |
1.1x |
| Contrast Ratio |
2200:1 Hz |
| Other Display Features |
BrilliantColorTM Technology, Throw Ratio: 1.95 (Wide) - 2.15 (Tele) |
| Lens Features |
| Aperture |
F2.41 - F2.55 |
| Focal Length |
21.8 - 24 mm |
| Focus Mechanism |
Manual Focus |
| Other Lens Features |
Uniformity: 90% |
| Audio Features |
| Audio Type |
Mono |
| Number of Speakers |
1 Speaker |
| Output Per Speaker |
2 W |
| Connectivity |
| USB |
1 |
| Headphone Jack |
Yes |
| Audio In |
1 x 3.5 mm Stereo Mini Jack |
| Audio Out |
1 x 3.5 mm Stereo Mini Jack |
| AV In |
RCA Composite Video In |
| Component Video In |
Component Video In |
| VGA |
2 x 15 Pin D-sub, 1 x 15 Pin D-sub |
| S Video |
Yes, Mini DIN 4 Pin x 1 |
| Other Connectors |
Dual VGA connectors for Fast and Smooth Transitions |
| Power Features |
| Power Supply |
AC 90 - 264 V||50 - 60 Hz |
| Power Consumption |
234 W (110 V AC), 209 W (220 V AC) |
| Power Consumption - Standby Mode |
0.5 W (110 V AC) |
| Other Power Features |
Power-Saving Design: Less than 14 W (Fan Speed at Minimum) ,Consumes Less than 1 Watt of Electricity in Standby Mode. |
| Operating Conditions |
| Operating Temperature |
5 °C - 35 °C |
| Humidity |
80 |
| Other Operating Conditions |
Storage Temperature: 0deg C - 60deg C, Humidity: 90% Maximum |
| Additional Features |
| Signal Type |
NTSC, PAL, SECAM |
| Keystone Adjustment |
Vertical: +40 / -35 Degree |
| Remote Control |
Yes |
| Controls |
Keystone Correction, Page Down, Page Up |
| Functional Modes |
EcoMode, Normal Mode, Power Saving Mode, Standby Mode |
| Security Slot |
Yes |
| Mounting |
Ceiling, Desk, Front, Rear |
| Other Features |
Security Password |
