| Capacity |
- 8GB flash drive1
- Holds up to 1,000 or 2,000 songs in 128-Kbps AAC format2
- Holds up to 3,500 or 7,000 iPod-viewable photos3
- up to 8 hours (8GB) of video
- Stores data via USB flash drive
|
| Display |
- 2-inch (diagonal) liquid crystal display with blue-white LED backlight
- 320-by-240-pixel resolution at 204 pixels per inch
|
| Audio |
- Skip-free playback
- Frequency response: 20Hz to 20,000Hz
- Audio formats supported: AAC (16 to 320 Kbps), Protected AAC (from iTunes Store), MP3 (16 to 320 Kbps), MP3 VBR, Audible (formats 2, 3, and 4), Apple Lossless, AIFF, and WAV
- User-configurable maximum
|
| Headphones |
- Earphones
- Frequency response: 20Hz to 20,000Hz
- Impedance: 32 ohms
|
| Mac system
requirements |
- Mac computer with USB 2.0 port
- Mac OS X v10.4.8 or later
- iTunes 7.4 or later5
|
| Windows system
requirements |
- PC with USB 2.0 port
- Windows Vista or Windows XP Home or Professional with Service Pack 2 or later
- iTunes 7.4 or later5
|
| Video |
- H.264 video, up to 1.5 Mbps, 640 by 480 pixels, 30 frames per second, Low-Complexity version of the H.264 Baseline Profile with AAC-LC audio up to 160 Kbps, 48kHz, stereo audio in .m4v, .mp4, and .mov file formats; H.264 video, up to 2.5 Mbps, 640 by 480 pixels, 30 frames per second, Baseline Profile up to Level 3.0 with AAC-LC audio up to 160 Kbps, 48kHz, stereo audio in .m4v, .mp4, and .mov file formats; MPEG-4 video, up to 2.5 Mbps, 640 by 480 pixels, 30 frames per second, Simple Profile with AAC-LC audio up to 160 Kbps, 48kHz, stereo audio in .m4v, .mp4, and .mov file formats
|
| Environmental
requirements |
- Operating temperature: 32° to 95° F (0° to 35° C)
- Nonoperating temperature: -4° to 113° F (-20° to 45° C)
- Relative humidity: 5% to 95% noncondensing
- Maximum operating altitude: 10,000 feet (3000 m)
|
| Input and
output |
- Dock connector
- 3.5-mm stereo headphone jack
|
| Power and battery
(3) |
- Built-in rechargeable lithium ion battery
- Playback time
- Music playback time: Up to 24 hours when fully charged
- Video playback time: Up to 5 hours when fully charged
-
|
| Charging |
- Charging via USB to computer system or power adapter (sold separately)
- Fast-charge time: about 1.5 hours (charges up to 80% of battery capacity)
- Full-charge time: about 3 hours
|
| Size and
weight |
- Height: 2.75 inches (69.8 mm)
- Width: 2.06 inches (52.3 mm)
- Depth: 0.26 inch (6.5 mm)
- Weight: 1.74 ounces (49.2 grams)
|
