| Overview | |
|---|---|
| Brand | Mikrotik |
| Model | CRS109-8G-1S-2HnD-IN |
| Platform | |
| OS | RouterOS |
| SFP DDMI | Yes |
| CPU | AR9344-DC3A-R |
| CPU Nominal Frequency | 600 MHz |
| CPU Core Count | 1 |
| RAM | 128 MB |
| Wireless | |
| Wireless chip model | AR9344-DC3A-R |
| Wireless standards | 802.11b/g/n |
| Ports/Slots | |
| 10/100 Ethernet ports | No |
| 10/100/1000 Ethernet ports | 8 |
| MiniPCI slots | No |
| MiniPCI-e slots | No |
| Number of USB ports | 1 |
| USB Slot Type | microUSB type AB |
| SFP ports | 1 |
| SFP+ ports | No |
| 802.3af support | Yes |
| Serial Port | RJ45 |
| Power | |
| Supported input voltage | 8 V - 57 V |
| Max. Power Consumption | 13 Watt |
| Power Jack | 1 |
| Othet Features | |
| PoE Out | No |
| PoE In | Yes |
| Voltage Monitor | Yes |
| CPU temperature monitor | No |
| PCB temperature monitor | Yes |
| Current Monitor | Yes |
| License level | 5 |
| Antenna gain DBI | 4 |
| No. of Chains | 2 |
| Operating Temerature Range | -30 Degree Celsius to +65 Degree Celsius Tested |
| Dimensions | |
| Dimensions | 200x145x45mm |
| Warranty | |
| Manufacturing Warranty | 1 Year on Software & 6 Months on Hardware. |
US$ 201.52
