| Overview | |
|---|---|
| Brand | TOTOLINK |
| Model | N150UM |
| Hardware | |
| Interface | USB 2.0 |
| Power | USB |
| Button | WPS button |
| LED Indicators | Status |
| Antenna | 2 *Internal Antennas |
| Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| RF Frequency | 2.4~2.4835GHz |
| Data Rate | 802.11n: Up to 150Mbps 802.11g: Up to 54Mbps (dynamic) 802.11b: Up to11Mbps (dynamic) |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES) |
| Output Power | < 20dbm (EIRP) |
| Channels | 1-11 (North America) 1-13 (General Europe) |
| Modulation Type | DBPSK, DQPSK, CCK and OFDM (BPSK,QPSK,16-QAM/ 64-QAM) |
| Reception Sensitivity | 135M: -65 dBm@10% PER 54M: -68 dBm@10% PER 11M: -85 dBm@8% PER 6M: -88 dBm@10% PER 1M: -90 dBm@8% PER |
| Network Settings | N/A |
| Wireless | Yes |
| NAT/QoS | Port Forwarding QoS DMZ |
| Function | -Good WiFi Connectivity -One Click WiFi Protected Setup |
| Firewall Settings | MAC/IP/PORT /URL Filter ACL DoS |
| Remarks | Fast-Click Button For High Security Connection |
| Environment | Operating Temperature: 0~40 (32~104) Storage Temperature: -40~70 (-40~158) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing |
Country of Origin | Country of Origin |
| Warranty | |
| Manufacturing Warranty | 3 Years |
US$ 11.07
