| General Features | |
|---|---|
| Brand | Kipor |
| Model | KGE4000E |
| Type | Petrol Generator |
| Engine Model | KG280GE |
| Engine Type | Single cylinder, air-cooled, four-stroke, OHV |
| Structure Type | Open Frame |
| Technical Specifications | |
| Rated Frequency | 50 Hz - 60 Hz |
| Rated Voltage | 115/230V - 120/240V |
| Rated Current | 26/13A - 29.2/14.6 A |
| Rated Rotation Speed | 3000 - 3600 r/min |
| Rated Output | 3.0 - 3.5 kVA |
| Max. Output | 3.3 - 4.0 kVA |
| Rated Power [KW/(r/min)] | 5.0/3000 5.5/3600 |
| DC 12V Output | Connection Pole Output |
| Voltage | 115/230V - 120/240V |
| Phase Number | Single |
| Power Factor (Cos Φ) | 1.0 |
| Insulation Grade | B |
| Pole number | 2 |
| Excitation Mode | Self-excitation & constant voltage (AVR) |
| Panel Type | Digital Panel |
| Receptacle | Two Receptacles |
| Noise level（7m）dB(A) | 69 |
| Starting System | Electric Starter |
| Combustion System | T.C.I |
| BorexStroke | 77x58 mm |
| Displacement | 277 ml |
| Compression Ratio | 8.5:1 |
| Cooling system | Air Cooled |
| Continuous Running Time | 12 hr |
| Battery capacity (V-Ah) | 12V 11Ah |
| Charging Generator Capacity (V-A) | 12V 8A |
| Starting Motor Capacity (V-kW) | 12V 0.4kW |
| Fuel | |
| Fuel Capacity | 25 L |
| Fuel Consumption | ≤374 g/kW.h |
| Fuel Type | Automotive Unlead Petrol (Gasoline) |
| Lubrication System | Splashed |
| Lube Oil Type | CD grade or SAE10W-30，15W-40 |
| Lube Capacity | 1.1 L |
| Dimensions & Weight | |
| Size (LxWxH) | 675 x 520 x 540 mm |
| Dry Weight | 78 Kg |
| Warranty & Service | |
| Manufacturing Warranty | 2 Year |
| Services | 3 Services Free of Cost |
US$ 588.38
