| Overview | |
|---|---|
| Brand | ASUS |
| Model | DSL-N12E |
| Specification | |
| Network Standard | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u, IPv4 |
| Product Segment | N300 complete networking; 300Mbps |
| Wi-Fi Data Rate | 802.11b : 1, 2, 5.5, 11Mbps 802.11g : 6,9,12,18,24,36,48,54Mbps 802.11n : up to 300Mbps |
| xDSL Data Rate | G.992.1 (T1.413) G.992.2 (G.dmt), G.lite G.992.3 (G.bis/ADS L2) G.992.5 (ADSL2+) Annex L (reach extended ADSL2) |
| Antenna | Fixed 2 or 5 dBi antenna x 2 *Antenna signal power may vary by region due local regulations and requirements |
| Operating Frequency | 2.4GHz |
| Security | 64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, Radius with 802.1x, WPS support |
| Management | Web-based GUI configuration Firmware upgraded, configuration data uploaded and downloaded via Web-based GUI Configuration backup and restore Diagnostics Log & Trace function |
| VPN Support | IPSec Pass-Throuth PPTP Pass-Through L2TP Pass-Through |
| Utilities | ADSL Setting Wizards Device Discovery Firmware Restoration |
| Ports | 1 x RJ11 for ADSL 4 x RJ45 for 10/100 BaseT for LAN |
| Button | WPS Button, Reset Button, Power Button |
| LED Indicator | Power, ADSL, Internet, WLAN, LAN x 4 |
| Power Adapter | AC Input : 100 ~240 V(50~60HZ) DC Output : 12 V/0.8 A |
| OS Support | Windows® 8 , 32bit/64bit Windows® 7 , 32bit/64bit Windows® Vista , 32bit/64bit Windows® XP , 32bit/64bit Mac OS X Linux |
| Size & Weight | |
| Weight | 300 g (Device Only) |
| Dimension (WxDxH) | 168 x 124 x 30 mm |
| Warranty | |
| Manufacturing Warranty | 3 Years |
US$ 36.76
