| General |
| Type |
XGA |
| Usage |
Business, Education |
| Device Chipset |
DLP |
| 3D Support |
Yes |
| Display Mode |
XGA, 1080i, 1080p, 480i, 480p, 576i, 576p, 720p |
| Resolution |
1024 x 768 pixels |
| Lamp |
190 W Osram |
| Lamp Life |
4500 hrs |
| Projection Distance |
39.3 inch to 26.24 ft |
| Display Features |
| Maximum Projection Size |
180 inch |
| Brightness |
2700 lm (Maximum) |
| Aspect Ratio |
4:3 (Native) |
| Zoom Ratio |
1.2x |
| Contrast Ratio |
2400:1 Hz |
| Other Display Features |
BrilliantColorTM Technology, Throw Ratio: 1.64 (Wide) - 1.97 (Tele) |
| Lens Features |
| Aperture |
F2.54 - F2.73 |
| Focal Length |
18.8 - 21.84 mm |
| Focus Mechanism |
Manual Focus |
| Other Lens Features |
Uniformity: 90%, Lens Offset Ratio: 110% |
| Audio Features |
| Audio Type |
Mono |
| Number of Speakers |
1 Speaker |
| Output Per Speaker |
2 W |
| Connectivity |
| USB |
1 USB Type B Port |
| Audio In |
1 x 3.5 mm Stereo Mini Jack |
| Audio Out |
1 x 3.5 mm Stereo Mini Jack |
| AV In |
RCA Composite Video In |
| Component Video In |
Component Video In |
| VGA |
2 x 15 Pin D-sub, 1 x 15 Pin D-sub |
| S Video |
Yes |
| RS-232 Connectors |
Mini DIN 9 Pin x 1 |
| Other Connectors |
AC Power Input Socket |
| Power Features |
| Power Supply |
AC 90 - 264 V||50 - 60 Hz |
| Power Consumption |
305 W (110 V AC) |
| Power Consumption - Standby Mode |
0.5 W (110 V AC) |
| Other Power Features |
Eco-Mode: 265 W |
| Operating Conditions |
| Operating Temperature |
0 °C - 35 °C |
| Humidity |
90 |
| Noise Level |
33 dB (Normal) |
| Other Operating Conditions |
Storage Temperature: -30deg C - 65deg C, Humidity: 90% Maximum, Shipping Temperature: -20deg C - 60deg C, Noise Output: 29 dB(A) Eco-Mode |
| Additional Features |
| Signal Type |
NTSC, PAL, SECAM |
| Keystone Adjustment |
Vertical: +/- 40° |
| Remote Control |
Yes |
| Controls |
Keystone Correction, Power On/Off |
| Functional Modes |
EcoMode, Normal Mode, Standby Mode |
| Security Slot |
Yes |
| Mounting |
Ceiling |
| Other Features |
Kensington Lock Slot, Password Protection |
