| Output | |
|---|---|
| Power Output - Front (RMS) | 167W |
| Power Output - Center (RMS) | 167W |
| Power Output - Surround (RMS) | 167W |
| Power Output - Subwoofer (RMS) | 165W |
| Power Consumption (in Operation) | 160W |
| Power Consumption (in Standby) | 0.3W |
| Power Output - Total (RMS) | 1000W |
| Amplifier | |
| S-Master | Yes (48-Bit) |
| Audio Line IN (Analogue) | 2 |
| USB | Yes |
| Speaker Terminal (Front/Centre/Surround/Subwoofer) | Yes / Yes / Yes / Yes |
| Movie | Yes |
| Portable Audio Enhancer | Yes |
| Dolby Digital | Yes |
| DTS | Yes |
| BRAVIA Sync | Yes |
| Control for HDMI | Yes |
| DEMO Mode | Yes |
| Dimmer | Yes |
| A/V Sync (Lip Sync) | Yes |
| Mic Input Jack (3.5mm) | 1 |
| Audio Return Channel (HDMI) | Yes |
| Bass Boost Function (Dynamic Bass on RM) | Yes |
| Night Mode (Normal/Plus) | Yes |
| Dolby Pro Logic | Yes |
| Video Signal OUT (HDMI) Upscale 720p/1080i for DVD | Yes |
| USB Memory | |
| Decoding Format for Sound (Playback) | MP3/WMA9/AAC |
| Decoding Format for Picture (Playback) | JPEG |
| Decoding Format for Video (Playback) | Xvid Home/MPEG4 Simple Profile |
| Encoding Format for Sound (Record) | MP3/WMA9/AAC |
| MP3 File Name/ID3Tag Ver. 1.1/ID3Tag Ver. 2.0) | Yes / Yes / Yes |
| Play Mode (Normal) | Yes |
| Play Mode (Shuffle) | Yes |
| Play Mode (Repeat) | Yes |
| Play Mode (Resume) | Yes |
| Tuner | |
| Band | FM |
| External FM/AM Antenna | Yes (75ohm) |
| Station Preset | FM20 |
| DVD/SACD/VCD/CD Player | |
| Type | 1-Disc Tray (Dust-Proof) |
| DVD/CD/Video CD | Yes/ Yes / Yes |
| CD | Yes |
| CD-R/CD-RW Playback | Yes / Yes |
| MPEG4 Simple Profile Playback | Yes |
| JPEG Playback | Yes |
| MP3 Playback | Yes |
| MP3/ID3Tag Ver.1.1/iD3Tag Ver.2.0 | Yes / Yes / Yes |
| Multi Disc Resume (DVD,VCD) | 10 Discs |
| VCD Version 2.0 | Yes |
| OSD | Yes |
| Progressive Scan (NTSC/PAL) | Yes / Yes |
| Precision Cinema Progressive | Yes |
| Tray Lock | Yes |
| Play Mode (Shuffle / Program / Repeat) CD/VCD/SA-CD only | Yes |
| Speakers | |
| Front Speaker Type (Grill) | Micro satellite (Fixed / Punched Metal) |
| Front Speaker System | 2 way (Full Range) |
| Front Speaker Woofer Unit | 65mm |
| Centre Speaker System | 1 way (Full Range) |
| Centre Speaker Unit | 1 |
| Centre Speaker Woofer Unit | 65mm |
| Surround Speaker Type (Grill) | Micro satellite (Fixed / Punched Metal) |
| Surround Speaker System | 1 way (Full Range) |
| Surround Speaker Woofer Unit | 65mm |
| Subwoofer - Active/Passive | Passive |
| Subwoofer Speaker Unit | 180mm |
| Front Speaker Tweeter Unit | 40mm |
| Surround Speaker Unit | 1 |
| Weight & Dimension | |
| Main Unit Size (W x H x D) | Approx. 430 x 55 x 350 mm |
| Main Unit Weight | Approx. 3.5kg |
| Front Speaker Size (W x H x D) | Approx. 108 x 225 x 95 mm |
| Front Speaker Weight | Approx. 0.6kg |
| Centre Speaker Size (W x H x D) | Approx. 261 x 82 x 79 mm |
| Centre Speaker Weight | Approx. 0.6kg |
| Surround Speaker Size (W x H x D) | Approx. 108 x 164 x 88 mm |
| Surround Speaker Weight | Approx. 0.5kg |
| Subwoofer Size (W x H x D) | Approx. 230 x 400 x 305 mm |
| Subwoofer Weight | Approx. 6.4kg |
| Karaoke | |
| Mic IN/VOLUME/ECHO | (Yes / Yes (by RC) / Yes (by RC) |
| Karaoke-PON (Only DVD Function) | Yes (by RC) |
| Multiplex (Only DVD Function) | Yes |
| Key Control (Only DVD Function) | Yes (by RC) |
| Warranty | |
| Manufacturing Warranty | 1 Year |
US$ 234.55
